Description
Bridon Dyform® Starfish PolyCore has high strength and proven extended rope life – prevents core corrosion and maintaining original design diameter.
Applications
- Trawl Warps
Advantages
- High strength
- Smooth periphery for reduced wear
- Superior bend fatigue
- Reduced elongation
Downloads
Features
CompactionDyform
CorePolycore
Steel Grades1770, 1960 or 2160
Lay typeLangs lay or Regular lay
Lay DirectionRH or LH
FinishBright or Galvanised
Bridon Dyform® Starfish PolyCore specification
Note for more detailed information please download the brochure above.
| Diameter | Weight | Minimum breaking load | |
| mm | kg/100 mtr | Tonnes | kN |
| 20 | 159.7 | 26.7 | 262 |
| 22 | 191.7 | 32.3 | 317 |
| 24 | 224.8 | 38.5 | 377 |
| 26 | 271.5 | 45.1 | 443 |
| 28 | 317.4 | 52.4 | 514 |
| 30 | 357.3 | 60.1 | 590 |
| 32 | 408.8 | 68.4 | 671 |
| 34 | 468.2 | 77.2 | 757 |
| 36 | 514.5 | 86.6 | 849 |
| 38 | 578.6 | 96.4 | 946 |
| 40 | 635.2 | 106.9 | 1048 |
| 42 | 700.3 | 117.8 | 1155 |
| 44 | 768.5 | 129.3 | 1268 |
This table is for guidance purpose only with no guarantee or warranty (express or implied) as to its accuracy. The products described may be subject to change without notice, and should not be relied on without further advice from Bekaert.
