Description
a real powerhouse, it can handle 2.5t or 5.3t depending on the model
But that’s not all: If your loads are above this, you can lift much heavier loads by using several Ludwig Hooks.
Different requirements, one is bound to fit: Ludwig Hook. For lifting applications indoors and outdoors, for all types of crane (such as mobile cranes, tower cranes, harbor cranes etc.). This makes your work both safer and more efficient. Because slinging is carried out directly, the
Ludwig Hook and slinging equipment remains attached to the crane hook. Ladders and lifting platforms are thus not required and your processes are speeded up at the touch of a button, whilst you increase safety as a result. The various different types of slinging in use are shown in our film below.
Types of slinging
Directly attached
Indirect attached
lacing course
Transport anchor
Explore more many applications
Technical data
-
Product
- Dead weight in kg
- Load capacity
- Dimensions in mm (H x W x D)
- Signal range
- Radio frequency
- Working voltage
-
Ludwig Hook
- 3,3 KG
- 2,5 T
- 120 199 102
- 50 M
- 868 MHZ
- 6 V
-
Ludwig Hook XL
- 6,8 KG
- 5,3 T
- 249 154 179
- 50 M
- 868 MHZ
- 6 V
Scope of supply and variants

-
Ludwig Hook 2,5T
- Remote control
- Load station
- Carrying strap
- Case
-
Ludwig Hook 5,3T
- Remote control
- Load station
- Carrying strap
- Case
