Offshore Bolt Shackles Type C
The shackles type C with bolt, nut and dowel pin TWN 0818 are intended to use in “Lifting Sets” for offshore containers acc. to DNVGL-ST-E271 and are used in portable offshore units acc. to DNV-ST-E273.
The manufacturing and testing requirements are based on the DIN EN 1677-1.
| Trade Size | Article-No. | Trade Size
[DIN 82101] |
Working Load Limit [t] |
Dimensions
[mm] |
Weight app. [kg] |
CAD
STEP |
CAD
IGES |
|||||
| h1 | b1 | b2 | d1 | d4 | d2 | |||||||
| 10-8 | F30310NV | 1.0 | 3.15 | 49 | 21 | 47 | 15 | 16 | 32 | 0.42 | Download | Download |
| 13-8 | F30320NV | 1.6 | 5.30 | 61 | 27 | 61 | 19 | 20 | 40 | 0.84 | Download | Download |
| 16-8 | F30330NV | 2.5 | 8.00 | 73 | 33 | 75 | 23 | 24 | 48 | 1.49 | Download | Download |
| 18/20-8 | F30340NV | 4.0 | 12.50 | 91 | 42 | 96 | 29 | 30 | 60 | 3.10 | Download | Download |
| 22-8 | F30350NV | 5.0 | 15.00 | 111 | 47 | 107 | 33 | 36 | 72 | 4.50 | Download | Download |
| 26-8 | F30360NV | 6.0 | 21.20 | 120 | 53 | 212 | 37 | 39 | 78 | 6.30 | Download | Download |
| 28-8 | F30370NV | 8.0 | 25.00 | 140 | 60 | 136 | 41 | 45 | 90 | 10.10 | Download | Download |
| 32-8 | F30380NV | 10.0 | 31.50 | 149 | 66 | 152 | 46 | 48 | 95 | 12.80 | Download | Download |
| 36-8 | F30390NV | 12.0 | 40.00 | 158 | 73 | 167 | 50 | 52 | 104 | 15.60 | Download | Download |
| 40-8 | F30400NV | 16.0 | 50.00 | 185 | 81 | 185 | 55 | 60 | 120 | 22.20 | Download | Download |
| 45-8 | F30410NV | 20.0 | 63.00 | 211 | 90 | 206 | 61 | 68 | 136 | 26.30 | Download | Download |
| The load capacities, manufacturing and testing requirements comply with the DNV-ST-E271 and some exceed the requirements of the DIN EN 1677-1 and DIN EN 1677-4. | ||||||||||||
