Description
Made By Elephant in Japan
Beta Hoist Ultra Small Electric Chain Hoist
This product is a testament to great engineering and offering a humane tool.
Capacity – 125 Kgs and 200 kgs
Single Phase – 220V – 50Hz
Lightest Electric Chain Hoist in the World. Helps reduce labour and fatigue.
200 kg hoist is only 7 kgs weight with 3 meter lift height. This makes it one of a kind.
This product can help with installation and maintenance even in the most compact and difficult to reach spaces.
Beta S-020 Dimensions
*All specifications herein are subject to change without prior notice.
Beta S-020 Specifications
|
Model
|
Beta S-020
|
|
Capacity ( kg )
|
200
|
|
Motor output ( W )
|
180
|
|
Short – time rating ( min )
|
25
|
|
Load time rate ( % ED )
|
30
|
|
Max. starting frequency ( times / h )
|
180
|
|
Power Source ( V )
|
Single phase 100
|
|
Rated current ( A )
|
4
|
|
Lifting speed ( m / min )
|
3.8
|
|
Standard lift ( m )
|
3
|
|
Headroom ( mm )
|
280
|
|
Push-button cord length ( m )
|
3
|
|
Load chain, diameter x pitch ( mm )
|
3 x 9.3
|
|
Power Cable ( m )
|
3 ( 1.25 m? x 3 cores )
|
|
Net weight ( kg )
|
7.2
|
|
Paint Color
|
Main body : Silver metallic
Top & Bottom Hook : Orange ( 10R 5.5 / 14.5 ) |
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 100V.
4 ) Headroom is less than above value.
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 100V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.
Instruction manual
Beta H-012 Dimensions
*All specifications herein are subject to change without prior notice.
Beta H-012 Specifications
|
Model
|
Beta H-012
|
|
Capacity ( kg )
|
125
|
|
Motor output ( W )
|
180
|
|
Short – time rating ( min )
|
25
|
|
Load time rate ( % ED )
|
30
|
|
Max. starting frequency ( times / h )
|
180
|
|
Power Source ( V )
|
Single phase 200 – 220
|
|
Rated current ( A )
|
2
|
|
Lifting speed ( m / min )
|
6.5
|
|
Standard lift ( m )
|
3
|
|
Headroom ( mm )
|
280
|
|
Push-button cord length ( m )
|
3
|
|
Load chain, diameter x pitch ( mm )
|
3 x 9.3
|
|
Power Cable ( m )
|
3 ( 1.25 m? x 3 cores )
|
|
Net weight ( kg )
|
7.2
|
|
Paint Color
|
Main body : Silver metallic
Top & Bottom Hook : Orange ( 10R 5.5 / 14.5 ) |
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.
Instruction manual
Beta H-020 Dimensions
*All specifications herein are subject to change without prior notice.
Beta H-020 Specifications
|
Model
|
Beta H-020
|
|
Capacity ( kg )
|
200
|
|
Motor output ( W )
|
180
|
|
Short – time rating ( min )
|
25
|
|
Load time rate ( % ED )
|
30
|
|
Max. starting frequency ( times / h )
|
180
|
|
Power Source ( V )
|
Single phase 200 – 220
|
|
Rated current ( A )
|
2
|
|
Lifting speed ( m / min )
|
3.8
|
|
Standard lift ( m )
|
3
|
|
Headroom ( mm )
|
280
|
|
Push-button cord length ( m )
|
3
|
|
Load chain, diameter x pitch ( mm )
|
3 x 9.3
|
|
Power Cable ( m )
|
3 ( 1.25 m? x 3 cores )
|
|
Net weight ( kg )
|
7.2
|
|
Paint Color
|
Main body : Silver metallic
Top & Bottom Hook : Orange ( 10R 5.5 / 14.5 ) |
1 ) Lifting speed is average value during lifting
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
2 ) Lift and length of push button cord is subject to change according to your request.
3 ) Control voltage of push button is 200 – 220V.
4 ) Headroom is less than above value.
Specifications and dimensions are subject to change without notice.
